A reliable vertical lift solution for your home garage or motor dealership. Unlocking the next level of parking above or below ground.
The robust four-post lift and safety lock system ensures smooth operation for your home garage. A steel base tray gives you a sturdy platform to lift a variety of vehicle sizes.
Control panels on both floors. Press the up button for lifting using the motor and pneumatic system to an above ground storage space. Or press the down button to lower using the hydraulic to an underground space.
Manufactured from high-strength steel, the four posts ensure a stable and balanced lift of larger and heavier vehicles.
Site Requirement
Suitable for indoor installation on a reinforced and level concrete foundation. The lift requires a compressed air supply required for the pneumatic system and a power supply for the control unit.
Specifications for an Elevator Lift
This is a highly customizable product suited to your needs, the following are specifications for a typical application.
Lift Capacity: 1 Vehicle
Max Lift Weight: 2000-5000kg
Height: Minimum 2 meters – variable
Powered by: Hydraulic cylinder + chains
Power required: 220-420V, 1 or 3 phase, 50/60Hz
Lock release: Electric auto release
Safety: 2 Safety chains with mechanical anti-falling lock
Outside Dimension: variable
Platform: Steel base tray platform
Maximum Car Dimension: variable
Lifting Speed: <60 seconds for 2 meters
Descending Speed: <45s for 2 meters Certification: TUV Rheinland
