Four post parking lifts are suited to larger and heavier vehicles. In addition to greater weight capacity comes a solution of sharing posts between two adjacent lifts – resulting in four bays with six posts. The platform cover plates prevent debris or oil from falling on the vehicle below.
The ground level vehicle is moved out before the top vehicle can be lowered. The heavy lifting of up to 3500kg is done by hydraulics and steel ropes (strong enough to lift a Rhinoceros!). It is operated using the key switch and has a limit switch in the top of the post which automatically stops the lift at the specified height.
Features
It is suitable for outdoor use, with galvanized screws and bolts ensuring a longer lifetime and resistance to corrosion. The surface of the posts is powder coated in a weather resistant finish that stands up to daily wear and tear. A pair of lateral protection wings prevent the vehicle from driving over the edge of the platform.
Product Description
Lift Capacity: 1 Vehicle
Number of parked cars: 2
Max Lift Weight: 3500kg
Powered by: 2.2kw Hydraulic
Power required: 220-420V, 1 or 3 phase, 50/60Hz
Lock release: Electric auto release
Height: Ground level 2100mm, 2nd floor limited by ceiling height
Safety: Dynamic anti-falling lock, wire rope detection lock
Outside Dimension: Length 5030mm , Width 2540mm, Height 2526mm
Maximum Car Dimension: Length 5030mm , Width 2100mm
Lifting Speed: 50s
Descending Speed: 45s
Certification: TUV Rheinland
